Equipped with CMOS sensor technologies perfected in Nikon’s DSLR cameras.

The Nikon FX format CMOS image sensor enables instantaneous capture of images in high definition. Digital Sight 10 allows the unprecedented high resolution of 6K and switching color and monochrome capture with a single camera. This high-performance model also features a high frame rate for fast focusing on high-definition images.

Observation with a wide field of view

A full-frame CMOS image sensor for instantaneous one-shot image capture of wide areas

A 25 mm field of view (FOV), possible in combination with inverted microscopes, and upright microscopes, enabling the capture of images over a wider area in one shot. Tiled images can be created efficiently, cutting the time required for screening.

*Upright microscopes are supported only by the ECLIPSE Ni Series (brightfield).

High-definition observation

Easily capture fine details with 6K pixel resolution and high image quality

Microscopic images can be captured at up to 6000 x 3984 pixels (23.9 megapixels), ideal for image analysis and observation of fine structures.

Digital Sight 10	Conventional model (DS-Ri2)

Fast live display

A frame rate that captures moving samples at the perfect instant

Digital Sight 10 is capable of live display of 6000 x 3984 pixel (23.9-megapixel) images at 9 frames/second or 1920 x 1080 pixel (2.1-megapixel) images at 66 frames/second. Fine focusing is easy and stress-free. By using the ROI mode, it is possible to shoot only any place at a higher speed.

High sensitivity and low noise

Ideal for fluorescence observation requiring a wide field of view and high definition

Digital Sight 10 achieves high sensitivity equivalent to ISO 200 in color mode and ISO 800 in monochrome mode. Clear fluorescence observation with a high signal-to-noise ratio is possible in both monochrome and color image acquisition

Ready for use in a wider range of observation scenarios

Color shooting and Monochrome shooting are possible with one unit (During manual operation).

Color Mode When inserting the color filter can shoot 400 to 680 nm in color	Monochrome mode When detaching the color filter capable of shooting 400 to 850 nm in Monochrome *Replace with monochrome IR filter

Electric switching function (During electronic operation (using the 1x electronic adapter))

Easy color mode switching, either manually or electronically

Digital Sight 10 makes it possible to easily switch the color mode either electronically or manually by using specialized imaging software for electronic switching or attaching/detaching filters to the slot at the bottom of the microscope camera for manual switching.

1x electronic adapter	Switch with a single action in the imaging software
*A 1x electronic adapter and a separate PC equipped with specialized imaging software, NIS-Elements, are required for electronic operation.

Achieves consistent shooting with a single sensor: A convenient all-in-one camera for multiple observation applications

A single sensor captures both color and monochrome images, for consistent appearance even when switching color mode. Easy image acquisition is possible without the hassle of using different cameras.

Brightfield (monochrome)	Brightfield (color)
Fluorescence (monochrome)	Fluorescence (monochrome)
Zebrafish (Objective: SHR Plan Apo 1X)

A monochrome mode that acquires even near infrared images: Fluorescence observation with little damage to biological samples

Digital Sight 10's monochrome mode supports near-infrared (700 nm) fluorescence image capture, normally difficult to achieve with conventional color cameras. As fluorescence sensitivity extends to the NIR region, this camera is suited to fluorescence image capture of thick samples and samples with weak phototoxicity.

For discriminating fine structures

Blurring and color bleeding are low even to the periphery, for images that are clear even when enlarged. ECLIPSE Ni supports everyday observation and inspection of samples with high resolution and high color fidelity.

For 3D imaging

ECLIPSE Ti2 takes advantage of a wide field of view (field number 25) to achieve high throughput even when capturing 3D or other large-size data. Combined with image processing, it enables the capture of clear images with a higher signal-to-noise ratio, even deep into subjects.

For model organisms

SMZ25/18 offers high definition at high frame rates. Capture perfect, bright images without missing high-speed biological reactions. Low noise makes this system ideal for time lapse imaging.

Integration with the comprehensive imaging software series

Nikon uses the NIS-Elements series as control software. NIS-Elements allows functions from basic imaging to control of the microscope and peripheral devices to be performed, as well as the measurement, analysis, and management of acquired images. Four basic packages and a variety of optional modules are available to suit every application and objective.

Free package The bundled free package offers functions for the display of scale on live images, full-screen display, and more. The simple operation screen makes shooting easy.	Documentation package The documentation package is equipped with measurement and report creation functions. It enables general microscopic image acquisition in fields from biomedical to industrial, and is expandable through optional added features such as EDF and databases.	Research package The research package enables the construction of advanced image acquisition systems, including multidimensional imaging (up to 4 dimensions for Br, 6 dimensions for Ar), through integration with systemized microscopes. Sets equipped with a rich range of image processing and analysis functions are available for every application.
